Mercedes-Benz S 560 e due for launch soon

By CARSIFU | 10 October 2018


STUTTGART: The third generation of the S 560 e plug-in hybrid from Mercedes-Benz is due to be launched. Order books in Europe opens from Oct 10.

This round, electric performance and charging times have been improved.

Only available with a long wheelbase, the V 222 S-Class gets a 9G-TRONIC plug-in-hybrid transmission and a new lithium-ion battery that's good for an all-electric range of around 50km. The hybrid drive system in the S 560 e combines the 270 kW/367hp of the V6 petrol engine with 90 kW/120hp of EQ Power to deliver a maximum system output of up to 350 kW/460hp. The vehicle launch is scheduled for this month. Prices start at 96,065 euro (RM460,000).

Plug-in hybrids are a key technology on the road to a locally emission-free future for the automobile. They offer customers the benefits of two worlds: in town they run in all-electric mode, while on long journeys they benefit from the range of the combustion engine. They make the vehicle more efficient overall because they can firstly recover energy and secondly allow the combustion engine to run in favourable operating ranges. Mercedes-Benz is driving forward with the development of its plug-in hybrids under the motto EQ Power.

Thead
t1
T2


The new cell chemistry with lithium-nickel-manganese-cobalt (Li-NMC) makes for a cell capacity of 37 Ah (previously 22 Ah). The highly efficient battery system in the S-Class comes, for the first time, from the wholly owned Daimler subsidiary Deutsche ACCUMOTIVE. The DC/DC converter previously housed separately in the luggage compartment is now installed in the power electronics housing. Despite an increase of around 50 percent in its energy content, the dimensions of the new battery are smaller than those of its predecessor.

Thanks to a water-cooled on-board charger with a capacity of 7.4 kW/10hp, the battery can be charged from 10 to 100 percent SoC (State of Charge) in 1.5 hours at a wallbox (Mercedes-Benz has introduced a new generation of these, too) if the full power is used. The same is possible in around five hours from a conventional domestic power socket.

The four operating modes of the hybrid powertrain management and the five driving programmes selectable by the driver control the interaction of the technology, meaning that the driver always has the final decision regarding whether to use the dynamic combination of engine and electric motor or opt for the luxury saloon's efficient mode. In the case of the latter, the management system activates the combustion engine as little as possible and also ensures optimum distribution of the battery charge for the current route.

To this end, the ECO Assist uses the data from all the driving assistance systems, including the navigation system, and indicates to the driver when it is best to come off the accelerator, both on the display and by means of the resistance point on the accelerator pedal.

The high-voltage on-board electrical system supplies not only the powertrain components and the vacuum pump of the regenerative braking system, but also the electric refrigerant compressor and the high-voltage heater booster. Both allow pre-entry climate control of the interior because they can also operate without the combustion engine.
